Hydrogen generator LC-H2 Series

Hydrogen generator LC-H2 Series are compact gas generators use a desiccant cartridge which can be refill or replaced by a new one. The LC-H2 hydrogen generators use the latest polymer electrolyte membrane (PEM) technology to produce pure hydrogen. LC-H2 models available: 100, 140, 180 cc/min and H2 purity:> 99.9995%. The LC-H2 series generators are ideal for: Ionization flame detector (FID), Small fuel-cell cylinder refills.

Additional Info

Technical specification:
Model LC-H2-100 LC-H2-140 LC-H2-180
H2  Flow rate cc/min 100 140 180
Installation power max 80 W 100 W 120 W
H2 Purity > 99.9995 %
Outlet pressure 7 barg
Dryer type Replaceable desiccant column
Display Resolution 128x64 touch screen ( operating parameters, system status, alarms)
Water quality Deionised or distilled > 10MΩ
Size (LxHxP)
25 x 30 x 32 cm
Outlet connection 1/8 Swagelock
Weight 10 kg
Supply voltage 90—240V ac   50/60 Hertz
Temperature and Humidity (max, non condensing) from 5°C to 35°C  and humidity 80% @25°C
Certification CE
