Industrial dispensing peristaltic pumps F6 series

Industrial dispensing peristaltic pumps F6 series provides flow rate from 2.11 ml/min to 12000ml/min depends on used model. Industrial peristaltic pump are ideal for industry production, large flow rates fluid transfer. Industrial peristaltic pump, use imported 4.3 inch industrial grade true color LCD screen, touch screen control, can preset the dispensing volume, dispensing time, pause time, copy numbers and back suction angle. Dynamic display the working status, dispensing parameters, setting parameters, system configuration in the same screen. Dispensing peristaltic pump F6 series are equipped with communication interface RS232, RS485 and MODBUS protocol.

Additional Info

Technical specification:
Model F6-3L F6-6L F6-12L
Flow rates
2.11 - 3600 ml/min* 3.0 - 6000 ml/min* 12.3 - 12000 ml/min*
Speed range 1-600 rpm
Speed resolution
0.01 rpm
Dispensing volume range 0.1 - 9999.99 ml
Dispensing volume resolution 0.01 ml
Dispensing time 0.5 – 9999.99 s
Pause time 0.5 – 9999.99 s
Time resolution 0.01 s
Copy number 1 – 9999.0
Back suction angle 0 - 360°
External control

Passive switch signal, such as foot pedal switch; Active switch signal: 5V, 12V and 24V for option

Communication interface RS232, RS485, MODBUS protocol
Power supply
AC 220V±10%, 50Hz/60Hz
Working condition
Temperature 0 do 40 C°, Relative humidity < 80%
Power consumption < 80 W < 180 W < 300 W
Dimension (LxWxH) 223x152x200 mm 283x192x218 mm 302x222x275 mm
Weight 5.02 kg 7.85 kg 13.14 kg
Acceptable pump head
DZ25-3L, DZ25-6L, YZ35
